Ankai 7M 21 seats mini bus

The F7 series 21 seats mini bus is an Ankai Coaster classic model, which brings together many leading technologies
  • Item No.:

    HFF6701KDE5FB
  • Payment:

    L/C,D/A,D/P,T/T
  • Product origin:

    China
  • Color:

    Optional
  • Shipping port:

    China port
  • Lead Time:

    60 days
  • Warning: Illegal string offset 'text' in /home/wwwroot/lamp01/domain/ankaiglobal.com/application/modules/front/views/scripts/companyshow/default/product_detail.phtml on line 88 Warning: Invalid argument supplied for foreach() in /home/wwwroot/lamp01/domain/ankaiglobal.com/application/modules/front/views/scripts/companyshow/default/product_detail.phtml on line 88
Follow Us :
  • Product Detail

21 seats minicity commuter minibus7m mini bus



The JAC special bus chassis successfully achieves the perfect unity of economy, safety,

comfort and reliability, and meets the needs of short- and medium-distance passenger

 transportation, tourism, groups, and business reception vehicles



Whole vehicle cathodic electrophoresis process

The electrophoresis process of the whole vehicle ensures that there are no new solder joints

during the assembly process after the completion of the painting of the whole vehicle,

maximizes the electrophoretic corrosion resistance performance, reduces potential safety hazards,

adapts to the changing climate environment, and the vehicle has a longer service life and more durable.

The whole vehicle is safe and anti-corrosion for ten years




Main Parameters

Dimensions(mm) 7005×2040×2645(2725、2785)
Seats 21+1(10-23)
G.V.W(kg) 6500
Front/rear Suspension(mm) 1150/1920
Wheelbase(mm) 3935
Fuel Tank Capacity(L) 85L
Maximum Speed(km/h) 100


Main Configurations

Engine Type YC4FA130-50 ISF3.8s5141 YC4FA130-30
Emission Standards Euro V Euro V Euro III
Gearbox YES
Clutch YES
Suspension System Leaf spring suspension、Front3/Rear 4
Front Axle Front Axle 2.5T/Disc Brake
Rear Axle Rear Axle 4.5T/Drum Brake
Service Brake Double circuit pneumatic brake、Self-adjusting arm
ABS YES
Steering System Power Steering
Tires 7.00R16
A/C Built-in A/C、Cooling capacity 14000W
Heater Optional
Side Window Sliding window
Passenger Door Pneumatic folding door
Others Vehicle Electrophoresis
