Golden Power Chain
The diesel engine matched with Ankai school bus series products is designed according to the golden power chain standard
of Ankai's independent intellectual property rights, with high power performance and fuel economy.
The fuel consumption per hundred kilometers is 0.5/L lower than similar domestic products.
High-strength front bumper
Using high-quality steel, through precision molds, high-level stamping technology and laser cutting technology,
the one-time formed bumper has high strength, good surface quality and good durability.
Safe sliding windows for effective ventilation
The lower closed and upper push-pull windows are used to fully ensure the safety of students,
while effectively meeting the ventilation needs of the car and ensuring continuous air circulation in the bus
Main Parameters
| Dimensions(mm) | 9995×2500×3170（3220） |
| Seats | 53+2+1（24-56） |
| G.V.W(kg) | 13000 |
| Front/rear Suspension(mm) | 1055/3240 |
| Wheelbase（mm） | 5700 |
| Fuel Tank Capacity(L) | 190L |
| Maximum Speed(km/h) | 80 |
Main Configurations
| Engine Type |
YC6J200-50
|
| Emission Standards |
Euro V
|
| Gearbox |
YES
|
| Clutch |
YES
|
| Suspension System |
Leaf spring
suspension/Front 4 Rear 5
|
| Front Axle |
Front Axle 4.5T/Disc
Brake
|
| Rear Axle |
Rear Axle 9T/Drum
Brake
|
| Automatic gap adjustment arm |
YES
|
| ABS |
YES
|
| Service Brake |
Double circuit air
brake
|
| Retarder |
YES
|
| Steering System |
Power Steering
|
| Tires |
255/70R22.5
|
| A/C |
Optional
|
| Heater |
Optional
|
| Video surveillance system inside and outside the vehicle |
YES
|
| Passenger door/security door |
Front pneumatic
swing-out door/rear open safety door
|
| Automatic fire extinguishing device |
YES
|
| Fore cabin temperature alarm |
YES
|
| Door alarm device |
YES
|
| Others |
Vehicle
Electrophoresis、Reversing monitor、Patrol system
|
